Intel® Socket 1151 for 9th / 8th Generation Pentium®/Celeron® 處理器
支援 Intel® Turbo Boost 技術2.0

*有關支援的 CPU 型號資訊，請參閱 tw.asus.com 網站內容。
* 是否支援 Intel® Turbo Boost Technology 2.0，需視 CPU 類型而定。
支援 Intel® 14 nm CPU

Intel® Z390

4 x DIMM, 最高可支援到64GB, DDR4 4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz 非ECC, 無緩衝區 記憶體 *
雙通道 記憶體架構
支援 Intel® Extreme Memory Profile (XMP)
*有關記憶體合格廠商清單（QVL）的相關資訊，請參閱 www.asus.com 網站或本使用手冊。
* 記憶體最大頻率會因處理器支援而異。

Integrated Graphics Processor- Intel® HD Graphics support
支援多 VGA 輸出 : HDMI/DVI-D 連接埠
- 支援 HDMI 最大解析度 4096 x 2160 @ 30 Hz
- 支援 DVI-D 最大解析度 1920 x 1200 @ 60 Hz
支援 Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™

支援 AMD CrossFireX™ 技術

1 x PCIe 3.0/2.0 x16 (x16 or x8+x4+x4) *
1 x PCIe 3.0/2.0 x16 (max at x4 mode)
2 x PCIe 3.0/2.0 x1

Intel® Z390 Chipset :
1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
4 x SATA 6Gb/s埠, 灰色
支援Raid 0, 1, 5, 10
Intel® Optane™ Memory Ready
Intel® CPU with Intel® Rapid Storage Technology support (RAID 0 & RAID 1)
PCIEX16_1 slot supports up to 3 Intel® PCIe NVME SSDs via a Hyper M.2 X16 series Card

Intel® I219V, 1 x Gigabit 區域網路控制器
Anti-surge LANGuard

Realtek® ALC887 8 通道 高傳真音效 CODEC
- 支援 : 插頭偵測, 前面板插孔指定功能
Audio Feature :
- LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path.
- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity

Intel® Z390 Chipset :
2 x USB 3.1 Gen 2 連接埠
Intel® Z390 Chipset :
8 x USB 3.1 Gen 1 連接埠 (4 位於主機板中)
Intel® Z390 Chipset :
4 x USB 2.0 連接埠 (4 位於主機板中)

華碩 EPU :
- EPU
ASUS 5X Protection III :
- ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
- ASUS Overvoltage Protection: World-class circuit-protecting power design
- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
ASUS Optimem II：
- Improved DDR4 Stability
華碩獨家功能 :
- MemOK! II
- AI Suite 3
- Ai Charger
華碩靜音散熱解決方案 :
- Stylish Fanless Design Heat-sink solution & MOS Heatsink
- ASUS Fan Xpert 4
華碩 EZ DIY :
- 華碩 CrashFree BIOS 3
- 華碩 EZ Flash 3
- ASUS O.C. Tuner
- ASUS UEFI BIOS EZ Mode
華碩 Q-Design :
- 華碩 Q-Slot
- 華碩 Q-DIMM
M.2 Onboard(The latest transfer technologies with up to 32Gb/s data transfer speeds)

1 x PS/2 鍵盤(紫)
1 x PS/2 滑鼠(綠)
1 x DVI-D
1 x HDMI
1 x LAN (RJ45) 連接埠
3 x 音訊插孔
2 x USB 3.1 Gen 2 Type-A,
4 x USB 3.1 Gen 1 Type-A

2 x USB 3.0 接頭支援額外的 4 USB 3.0 連接埠 (19-pin)
2 x USB 2.0 接頭支援額外的 4 USB 2.0 連接埠
1 x COM 接頭連接埠
4 x SATA 6Gb/s 接頭
1 x CPU 風扇接頭 (1 x 4 -pin)
2 x 機殼風扇接頭 (2 x 4 -pin)
1 x S/PDIF 輸出接頭
1 x 24-pin EATX 電源接頭
1 x 前面板音訊接頭 (AAFP)
1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x Clear CMOS 跳線
1 x AIO_PUMP connector (1 x 4 -pin)
1 x 8-pin EATX 12V Power connectors
1 x MemOK! II switch(es)
1 x System panel connector
1 x Mono Out header
1 x RGB Header

使用者手冊
I/O 擋板
2 x Serial ATA 6.0Gb/s 纜線
1 x M.2 Screw Package
1 x SCD (by region)

128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F9 Search, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information

WfM 2.0, DMI 3.0, WOL by PME, PXE

Drivers
ASUS Utilities
ASUS EZ Update
Anti-virus software (OEM version)

Windows® 10 64-bit

mATX 主機板尺寸
9.6 吋 x 9.6 吋 ( 24.4 公分 x 24.4 公分 )
