Intel® Socket 1151 for 8th Generation Core™ Processors
* 有關支援的 CPU 型號資訊，請參閱www.asus.com 網站內容。
Supports Intel® 14 nm CPU
* The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.

Intel® Z370

2 x DIMM, Max. 32GB, DDR4 4333(O.C.)/4200(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133(O.C.) MHz Non-ECC, Un-buffered Memory
雙通道 Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
* 是否支援 Hyper DIMM 需視個別 CPU 的實體特性而定。
* 有關記憶體合格廠商清單（QVL）的相關資訊，請參閱 www.asus.com 網站或本使用手冊。

Integrated Graphics Processor- Intel® HD Graphics support
支援多 VGA 輸出 : HDMI/DisplayPort ports
- 支援 HDMI 最大解析度4096 x 2160 @ 24 Hz
- Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz
最大共享記憶體1024 MB
Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™

1 x PCIe 3.0 x16

Intel® Z370 Chipset :
1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*1
1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)*1
4 x SATA 6Gb/s port(s)
Support Raid 0, 1, 5, 10
Intel® Rapid Storage Technology supports
Supports Intel® Smart Response Technology*2
Intel® Optane™ Memory Ready *3

Intel® I219V
Anti-surge LANGuard
ROG GameFirst Technology

Wi-Fi 802.11 a/b/g/n/ac
Supports dual band frequency 2.4/5 GHz
Supports MU-MIMO

Bluetooth V4.2

SupremeFX 8通道 高傳真音效 CODEC
- Dual Headphone Amplifiers
- 支援 : Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Impedance sense for front and rear headphone outputs
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
- SupremeFX Shielding Technology
- Supports up to 32-Bit/192kHz playback
Audio Feature :
- Optical S/PDIF out port(s) at back panel
- Sonic Radar III
- Sonic Studio III

ASMedia® USB 3.1 Gen 2 controller :
1 x USB 3.1 Gen 2 front panel connector port(s) (Support 3A power output)
Intel® Z370 Chipset :
6 x USB 3.1 Gen 1 port(s) (4 at back panel, , 2 at mid-board)
Intel® Z370 Chipset :
6 x USB 2.0 port(s) (4 at back panel, , 2 at mid-board)

ROG RAMCache II
ROG CPU-Z
ROG CloneDrive
Overwolf
GameFirst IV
ROG Aura
- Aura Lighting Control

OC Design - ASUS PRO Clock Technology
- Full BCLK range for extreme overclocking performance
5-Way Optimization by Dual Intelligent Processors 5
- Whole system optimization with a single click! 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 4, and Turbo App together, providing better CPU performance, efficient power saving, precise digital power control, whole system cooling and even tailor your own app usages.
TPU
- Auto Tuning, TurboV, GPU Boost
- Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors
Gamer's Guardian:
- DRAM Overcurrent Protection
- DIGI+ VRM
- SafeSlot
- ESD Guards on LAN, Audio,and USB ports
ASUS EPU :
- EPU
華碩獨家功能 :
- AI Suite 3
- Ai Charger
- ESD Guards
AURA :
- Aura Lighting Control
- Aura Lighting Effects Synchronization with compatible ASUS ROG devices
- Aura Addressable Strip Header(s)
ASUS Q-Design :
- ASUS Q-Shield
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
Gaming Aesthetics :
- AURA-RGB Lighting

1 x DisplayPort
1 x HDMI
1 x LAN (RJ45) 連接埠
1 x 光纖 S/PDIF 輸出
5 x 音訊插孔
4 x USB 3.1 Gen 1
4 x USB 2.0
1 x ASUS 2x2 Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v4.2 module

4 x SATA 6Gb/s 接頭
1 x Aura Addressable Strip Header(s)
1 x CPU 風扇接頭
1 x 機殼風扇接頭
1 x AAFP connector
1 x 24-pin EATX 電源接頭
1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (PCIE mode only)
1 x 系統面板
1 x AIO_PUMP connector
1 x 8-pin ATX Power connector
1 x Clear CMOS jumper(s)
1 x T_Sensor Connector
1 x USB 3.1 Gen 2 front panel connector
1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)

使用者手冊
M.2 2242 mounting kit
4 x Serial ATA 6.0Gb/s 纜線
I/O Shield
2 x M.2 Screw Package
1 x CPU installation tool
1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n compliant)
1 x SCD
1 x Panel cable
1 x STRIX series sticker

128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, SM BIOS 3.0 ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information

Drivers
ASUS Utilities
ASUS EZ Update
Anti-virus software (OEM version)

Windows® 10 64-bit

Mini ITX 主機板尺寸
6.7 inch x 6.7 inch ( 17 cm x 17 cm )
